4.7uF 50VDC Electrolytic RB Capacitor

4.7uF 50VDC Electrolytic RB Capacitor.

An electrolytic capacitor uses an electrolyte (a liquid or gel containing a high concentration of ions) to achieve a large capacitance than the other capacitor types. These electrolytic capacitors are polarized, meaning that the voltage on the positive terminal must always be greater than the voltage on the negative terminal. They are commonly used as filters in devices in various power supplies to reduce the voltage ripple as well as input and output smoothing as an LPF.

Features:

Ripple Current mA: 35.
Mounting: RB - PC Mount.

Specifications:

Capacitor type: Electrolytic.
Polarised Capacitor: Yes.
Capacitance: 4.7µF.
DC Voltage: 50V.
Operating Temperature  105°C.
Height: 11mm.
Diameter: 5mm.
Component Type: Electrolytic Capacitor.
Pack Quantity: 1.
Pitch: 2mm.
Capacitor mount type: Through Hole.
Capacitor connector type: Solder Legs.
Component package : Radial
Capacitor number of legs: 2.
Capacitor marking code: Printed.

Package includes: 1x 4.7uF 50VDC Electrolytic RB Capacitor.
